快脉冲传输线分布电容补偿模型和计算方法

陈宇晓, 杨谟华, 唐丹

陈宇晓, 杨谟华, 唐丹. 快脉冲传输线分布电容补偿模型和计算方法[J]. 电子科技大学学报, 2006, 35(6): 909-912.
引用本文: 陈宇晓, 杨谟华, 唐丹. 快脉冲传输线分布电容补偿模型和计算方法[J]. 电子科技大学学报, 2006, 35(6): 909-912.
CHEN Yu-xiao, YANG Mo-hua, TANG Dan. Distributed Capacitance Compensation Model and Computing Method for Fast-Pulse Transmission Line[J]. Journal of University of Electronic Science and Technology of China, 2006, 35(6): 909-912.
Citation: CHEN Yu-xiao, YANG Mo-hua, TANG Dan. Distributed Capacitance Compensation Model and Computing Method for Fast-Pulse Transmission Line[J]. Journal of University of Electronic Science and Technology of China, 2006, 35(6): 909-912.

快脉冲传输线分布电容补偿模型和计算方法

基金项目:

国家自然科学基金资助项目(10176001)

详细信息
    作者简介:

    陈宇晓(1972-),男,博士生,副研究员,主要从事微电子学、军备控制技术方面研究.

  • 中图分类号: TN817;TN701

Distributed Capacitance Compensation Model and Computing Method for Fast-Pulse Transmission Line

  • 摘要: 根据传输线理论和分布参数理论提出等效分布电容补偿模型,得出快脉冲传输线上多个电容负载造成取样波形失真,并给出两种匹配计算方法和公式。数值计算结果表明等效分布电容法对均匀分布的多个小负载电容脉冲传输线具有很好的补偿作用。
    Abstract: According to transmission line theory and distributed parameter theory, it is pointed out that the sampling waveforms distortion is produced by multi-capacitance loading of fast-pulse transmission line. The equivalent distributed capacitance compensation model is proposed, the two matching computing methods and formulas are given. The results of numerical computation show that pulse transmission line of multi-small-loading capacitance with proportional spacing can be well compensated by the equivalent distributed capacitance method.
