基于三轴线性插补的的裁剪跟随方法

吴献钢; 徐丽梅; 黄大贵

doi:10.3969/j.issn.1001-0548.2014.03.027

基于三轴线性插补的的裁剪跟随方法

1.
电子科技大学机械电子工程学院成都 611731;
2.
电子科技大学空天科学技术研究院成都 611731

详细信息

作者简介:
吴献钢(1975-),男,讲师,主要从事运动控制、数控技术方面的研究.

中图分类号: TP29
计量
- 文章访问数: 4476
- HTML全文浏览量: 134
- PDF下载量: 62
出版历程
- 收稿日期: 2013-03-30
- 修回日期: 2013-09-22
- 刊出日期: 2014-06-14

Tangential Following Method Based on 3-Axis Linear Interpolation

1.
School of Mechanical Electronic and Industrial Engineering,University of Electronic Science and Technology of China Chengdu 611731;
2.
School of Aeronautics and Astronautics,University of Electronic Science and Technology of China Chengdu 611731

摘要

摘要: 针对多层自动裁床片式裁刀的运动控制，提出了一种新型的裁刀跟随算法，通过普通运动控制器的三轴线性插补功能来实现任意二维曲线的插补跟随. 先将曲线按照精度要求离散为直线段，然后将裁片轨迹划分为若干直线组成的节段，以刀片围绕刀尖点的旋转运动实现节段内直线间的转接. 该算法重点考虑刀具形状参数的影响，过剪量可控. 误差分析和实验表明，该算法有效可行. 与已有的技术相比，具有插补跟随精度高，实现成本低的特点.
- 三轴插补 /
- 自动裁床 /
- 数控裁剪机 /
- 运动控制 /
- 切向跟随
Abstract: A new tangential following motion control method of knife blade is proposed for automatic fabric cutting. By this method, following interpolation algorithm of arbitrary 2D curves can be implemented by ordinary motion controllers with a 3-axis linear interpolation function. After curves are discretized into broken lines according to required precision, each cutting piece contour can be divided into a number of segments composing of several lines. And transition between lines in the same segment is realized by rotating knife blade around tool nose. Error analysis and experiments showed that this method, with cutter compensation and adjustable overcutting, is effective and practicable. Compared with existing technology, it provides higher precision and lower cost.
- 3-axis interpolation /
- automatic cutting table /
- CNC cutting machine /
- motion control /
- tangent following
