用Pro/E对过约束运动平台动态仿真分析研究

基金项目:

国家自然科学基金(60572007)

详细信息

Dynamic Simulation and Analysis Based on Pro/E of the Translational Platform with Redundant Constraints

1.
School of Mechatronics Engineering,University of Electronic Science and Technology of China Chengdu 610054;
2.
Southwest Petroleum University Chengdu 610500

摘要: 针对过约束多体运动机构的动态受力分析难点，以一个具体的多曲轴运动平台为例，提出一种基于Pro/E中Mechanism仿真模块进行动态仿真的解决方法。在Pro/E中进行了3维建模；针对分析的重点，对系统模型进行了适当简化；并结合虚拟样机技术在Pro/E中的具体运用，对简化模型进行动态仿真；并运用仿真结果分析了各类因素对该机构运动及受力的影响，提出了优化设计方案。
- 动态仿真 /
- 运动平台 /
- 多体系统 /
- 过约束
Abstract: Aiming at the problems of dynamic analysis on multi-body systems with redundant constraints, a solution based on the dynamic simulation in Mechanism module of Pro/E is proposed and illustrated with an example of a translational platform with multicrank. A three-dimensional model of the system is built simplified to fit the pivot in the research. Comprehensive dynamic simulation is performed based on the application of virtual prototyping technology in Pro/E. The factors which impact the motion and reacting forces of the platform are analyzed with simulation results. The optimized design is then considered.
- dynamic simulation /
- motion platform /
- multi-body systems /
- redundant constraints
